A broaching machine is one that is used for machining or finishing the surface of different kinds of metal components.
It will generally consist of a work table or other fixtures which are capable of holding parts in place while a broaching tool passes over them. Some kind of drive mechanism will be required to power the broaching tool in order to achieve the desired type of finish on the metal component.
Here are some of the most commonly used terms associated with broaching machines, so that you will have a better understanding of exactly what these extremely useful tools are all about.
1. Drive mechanism
The drive mechanism of any broaching machine will always consist of an electromechanical or hydraulic powered system, which is capable of powering the broaching tool. The specific function of a drive mechanism is to either push or pull a broaching tool over the surface of any metallic component so that the desired finish can be imparted to the part. The component being operated on will be static throughout the process and is simply the object of the finishing process of the broaching tool.
2. Broaching tool
A broaching tool is one that performs cutting by using graduated cutting teeth which are fixed all in a row. Each one of these cutting teeth is capable of removing a small part of the surface of the metal being operated on. As the teeth become larger and higher, a bigger chunk of metal gets removed from the surface, and the overall task of the broaching tool gets accomplished. There are two main types of broaching tools, those being linear and rotary. Linear broaching involves running the broach against the surface of the component being cut, so as to achieve the desired finish. Rotary broaching is a rapid machining method that serves to cut shapes into a workpiece and is generally used in blind operations or through-hole operations.
The worktable in a broaching operation is some kind of a fixed table that tilts and grips the component part being operated on. The center of the broaching tool and the center of the part must be aligned using a 1° offset so that a scalloping effect can be accomplished on the surface of the metal.
4. Broaching fixtures
Broaching fixtures are used whenever it’s necessary to fix a workpiece in place so that it can be operated on by a broaching tool. The broaching fixture has the function of maintaining the broach in an exact position so that a precise finish can be obtained.
5. Component tray
In any broaching operation, the component tray will serve to recycle drained oil on any broached components back into the broaching machines. This recycling of the oil prevents waste and ensures that the broached components remain lubricated throughout the process.
The pull bridge of a broaching operation always has to be guided using bars that are chrome-plated and extremely tough. This is necessary so that movement during a broaching operation is smooth and continuous, with no jerks or exaggerated movements that would degrade the finishing process.
7. Stroke adjustments
The positioning of a stroke can be modified using two different limit switches. These limit switches are positioned at the upper and lower turnaround points of a broaching machine, and they are necessary for security purposes.
8. Broaching Safety
